Eccentric Segmental Ball Control Valve, 1-16 IN, 150-300 LB

Eccentric Segmental Ball Control Valve, 1-16 IN, 150-300 LB
Eccentric Segmental Ball Control Valve, 1-16 IN, 150-300 LB

Key Specifications / Features

Model no.: CNCV-240425-BACV-01

Discover our range of eccentric segmental ball control valves, meticulously manufactured to meet the highest industry standards. Available in sizes ranging from 1 to 16 inches and pressure classes from 150 to 300 LB, these valves offer precise control and reliable performance. Crafted from premium materials such as carbon steel, stainless steel, and alloy steel, they ensure durability and resistance to corrosion. With seat leakage designed to meet ANSI B16.104 Class V standards, our valves are suitable for a wide range of industrial applications.

Categories

Tags:

Request a quote

Detail Information


Product Name: Eccentric Segmental Ball Control Valve
Key Features: Eccentric Segmental Ball Structure
Size Range: 1 Inch - 16 Inch, DN25-DN300
Pressure Rating: Class 150 - 300 LB, PN10 - PN64, 1.0 - 6.4 Mpa
Body Material: ASTM A216 WCB/WCC, ASTM A351 CF8/CF8M, ASTM A217 WC6/WC9
Seat Leakage: ANSI B16.104 Class V
Rangeability: 100:1
Connection: Flanged, Wafer
Temperature Range: -196℃ to 538℃
Flow Characteristic: Approximate Linear
