Product Name: Electric Angle Control Valve
Key Feature: Single Seated
Body Material: Stainless Steel ASTM A351 CF8
Size: 4 Inch, DN100
Pressure: Class 150 LB, PN16
End Connection: Flanged Ends
Actuation: Electric Actuator
Product Range
Body Material: Carbon Steel, Stainless Steel
Seal Type: Single Seat
Size Range: 3/4-8 Inch, DN20-DN200
Pressure Rating: Class 150-1500 LB, PN16-PN250
Working Temperature: -20°C to 250°C
Seat Leakage: ANSI B16.104 Class IV, Class V, Class VI
Flow Characteristic: Equal Percentage, Linear, Quick Open
Actuator Options: Electric Actuators
Control Model: On Off Type or Regulation Type
Voltage: DC 12-24V (±10%), AC 110-220V, 50/60Hz
