Product Name: Triple Eccentric Butterfly Control Valve
Key Features: Multi-level Valve Seat, Triple Eccentric Structure
Size Range: 2 Inch - 48 Inch, DN50-DN1200
Pressure Rating: Class 150 - 600 LB, PN10 - PN64, 1.0 - 6.4 Mpa
Body Material: ASTM A216 WCB/WCC, ASTM A351 CF8/CF3/CF8M/CF3M
Seat Leakage: ANSI B16.104 Class VI
Rangeability: 30:1
Connection: Flange, Wafer
Temperature Range: -45℃ to 250℃
Flow Characteristic: Approximate Equal Percentage
