Product Name: Electric Butterfly Control Valve
Body Material: Carbon Steel, Stainless Steel
Lining Material: NBR, EPDM Rubber
Size Range: 2-40 Inch, DN50-DN1000
Pressure Rating: Class 150 LB, PN10, PN16, PN25
End Connection: Flanged, Wafer, Lug
Flow Characteristics: Approximate Quick Open
Ambient temperature: -30°C to 70°C
Working Temperature: -9°C to 120°C
Applications: Gas, Water, Steam, Oil, Corrosive Medium, etc
Actuator Options:
Multi-turn Electric Mounting
Fine Small Electric Mounting
QT Intelligent Electric Mounting
(with Explosion-proof Type and Handwheel Device)
Power Supply Voltage: AC 220V, AC 380V
Feedback Signal: 4-20mA
Electric Rubber Lined Butterfly Control Valve
1. Concentric Structure: The valve is designed with a concentric structure, which enhances its mechanical performance and ensures a uniform distribution of pressure across the valve.
2. Enhanced Sealing: The rubber lining provides excellent sealing capabilities, preventing leaks and ensuring the valve's reliability in various applications.
3. Longevity: The use of high-quality NBR EPDM rubber lining contributes to the valve's long service life, reducing the need for frequent replacements and maintenance.
4. Corrosion Resistance: The electric rubber-lined butterfly valve is suitable for use in environments with corrosive media, making it an ideal choice for chemical and environmental protection industries.
5. Versatility in Media Handling: It can handle a wide range of media, including gases, oils, steam, water, and corrosive substances, making it a versatile option for various industrial applications.
6. Temperature Tolerance: The valve is designed to operate effectively at temperatures up to 120°C, accommodating a broad spectrum of industrial processes.
7. Electric Actuation: The integration of an electric actuator simplifies operation, allowing for remote control and automation of the valve, which is particularly beneficial in environments where manual operation is challenging or impractical.
