Product Name: Unbalanced Labyrinth Control Valve
Trim: Unbalance Trim, Labyrinth Cage Combination, Quick Tear Down
Size Range: 3/4 Inch - 12 Inch, DN20-DN300
Pressure Rating: Class 150 LB - 2500 LB, PN16-PN420, 1.6-42.0 Mpa
Body Material: ASTM A216 WCB, WCC, A217 WC6, WC9, ASTM A105
Seat Leakage: ANSI B16.104 CLASS V (Standard, Metal Seat), CLASS VI (Optional, Soft Seat)
Connection: Flange, Welding
Rangeability: 30:1
Temperature Range: -196℃ to 538℃
Flow Characteristic: Equal Percentage, Linear
