Product Name: Plastic Lined O-type Ball Control Valve
Key Features: O-type Cut-off Ball Valve, 90° Turning Angle
Material: ASTM A216 WCB
Size: 1-1/2 Inch, DN40
Pressure: Class 150 LB, PN16
Lined Material: F46, PFA Fluorine Plastic
Connection: RF Flange
Flow Characteristic: Quick Open
Product Range
Size Range: 1/2-10 Inch, DN15-DN250
Pressure Rating: PN6/PN10/PN16/PN20, Class 150 LB
Body Material: ASTM A216 WCB, WCC, ASTM A217 WC6, WC9, ASTM A352 LCB, LCC, ASTM A351 CF8, CF8M, CF3, CF3M
Temperature Range: -30℃ to +150℃
Leakage: Zero Leakage, as pe API 6D, API 598
Actuator Options: Pneumatic or Electric Actuator
